Greensun Stacked Household Energy Storage All-in-one Machine G-AIO-200-S6K/S11K Technical Datasheet  Model G-AIO-S6K G-AIO-S11K Input Sources L+N+PE Rated Input Voltage 90-280VAC±3V (APL Mode) 170-280VAC±3V (UPS Mode) Frequency 50/60Hz (Auto Adaptive) Rated Capacity 6200W 11000W Output Voltage 220/230/240VAC±5% Output Frequency 50/60Hz±0.1% Waveform Pure Sine Wave Peak Power 12400W 22000W PV Charging Mode MPPT MPPT Dual MPPT Max PV Input Power 6200W 2*5500W MPPT Tracking Range 120-500Vdc 90-500Vdc Best Voltage 300-400V 300-400V MAX.Charging Current 120A 150A  Model G-AIO-200 Battery Chemistry LiFePO4 Built-In Circuit Breaker 125A 2P Nominal Voltage 51.2V Nominal Capacity 200Ah Operating Voltage 44.8~57.6V Battery Module Qty Optional Nominal Energy 10.24Kwh Max. Continuous 100 Cycle Life ≥6000 90%DOD Mode G-AIO-200-S6K Inverter Power 6KW 6KW 6KW Battery Module Qty 1 2 3 Battery Capacity 10.24kwh 20.48kwh 30.72kwh Dimension L*W*H (Kickstand not included) 700*241.5*1140mm 700*1580*241.5mm 700*2020*241.5mm Weight Approximate (kg) 134.6kg 226.6kg 318.6kg Installation Method Floor-Mounted Operating Temperature (°C) Charge : 0℃~55℃, Discharge : -10℃ ～ 55℃ Storage Temperature (°C) -10~40°C Relative Humidity (%) 5%-95% Altitude (m) ＜3000m Model G-AIO-200-S11K Inverter Power 11KW  11KW  11KW  Battery Module Qty 1 2 3 Battery Capacity 200 200 200 Dimension L*W*H (Kickstand not included) 700*241.5*1140mm 700*1580*241.5mm 700*2020*241.5mm Weight Approximate (kg) 134.6kg 226.6kg 318.6kg Installation Method Floor-Mounted Operating Temperature (°C) Charge : 0℃~55℃, Discharge : -10℃ ～ 55℃ Storage Temperature (°C) -10~40°C Relative Humidity (%) 5%-95% Altitude (m) ＜3000m System Components Intelligent monitoring software Our Advantages 1. We are a real factory and have strict requirements on the quality of products.   2. We provide OEM services for many leading companies around the world.     We also have long-term cooperation with Solis, Deye,Growatt, Must,SMA and other tier-one brands.   3. As a factory, we have better control over product costs.   4. Both production and delivery are very fast.   5. Also, we provide stable and long-term after-sales service.

Greensun Rack Mount Lithium Ion Battery Parallel Connection Support Capacity from 100KWH to 1MWH 10-15 Years warranty. 20 Years Design Life Also offer complete solar systems solution for home and commercial use.

Container lithium battery energy storage systems, such as 500kwh, 1mwh, 2mwh, etc., usually store power when the power is surplus, and output the stored power to the grid through the inverter when the power is insufficient. When the power grid is out of power, the lithium battery energy storage system can act as an independent inverter power supply to provide AC power to important loads, thereby ensuring the needs of users. In areas with high electricity costs, it is also possible to build a large energy storage system solely to sell electricity. One stop solution service, free design. 12 years warranty, more than 20 years lifetime UL CE MSDS certificates

LiFePO4 Battery 51.2V 280AH 314AH 12 Years Warranty Support Parallel Connection UN38.3, MSDS, CE Certificates

DEYE Hybrid Solar Inverter 60KW 80KW (Max. 10 pcs parallel ) SUN-60K-SG02HP3-EU-EM6 SUN-80K-SG02HP3-EU-EM6 Three Phase | 6 MPPT | Hybrid Inverter | HV Battery Supported

Greensun Rack Mount Lithium Ion Battery Parallel Connection Support Capacity from 100KWH to 1MWH 10-15 Years warranty. 20 Years Design Life Also offer complete solar systems solution for home and commercial use.

N-Type Solar Panels Bifacial Type 700W - 730W Monocrystalline High Efficiency 2384*1303*30MM
